SS400 Carbon Steel Plate

JIS G3101 SS400 steel is the most common low-carbon steel, and there are many equivalent steel grades in other countries. For example, the European standard is EN10025-2 S235JR; the American standard is ASTM A36, the German standard is DIN17100 ST37-2, and the Chinese standard is GB/T 700-2006 Q235. The mechanical properties of these grades are similar, but there are slight differences depending on regional standards.

Chemical Composition
The carbon content of SS400 steel plate is between 0.16% and 0.22%, which is a low-carbon steel plate. In addition to carbon, it also contains appropriate amounts of phosphorus (P), sulfur (S) and other elements. Among them, the content of P and S is strictly controlled, because P will increase the cold brittleness of steel, and S will cause hot brittleness of steel. The content of P and S in SS400 steel must be less than 0.050%.

Mechanical Properties
The following table shows SS400 material mechanical properties, such as yield point or yield strength (yield stress), tensile strength and elongation.

Product Parameters

Application fields
Due to its excellent performance, SS400 steel plates are widely used in many fields such as construction, machinery, bridges, ships and vehicle manufacturing. The following is a detailed summary of the application fields of SS400 steel sheets:

1. Construction field
Building structure: SS400 steel sheets are often used to manufacture frames, floor slabs, walls and other components of various building structures. These components are essential to improving the overall strength and stability of the building. In the construction field,SS400 steel plates are favored for their good bearing capacity and durability.
Steel structure: SS400 steel sheets are also often used to manufacture steel structures, such as steel structure frames, supports and connectors, which ensure the safety and stability of buildings in high-rise buildings, large commercial buildings and public facilities.

2. Bridge field
Bridge structure: SS400 steel sheets play an important role in bridge construction. They are often used to manufacture bridge beams, beams, supports and other components. These components need to withstand huge loads and complex stress states, and SS400 steel sheets can meet these requirements due to their excellent mechanical properties and processing properties.

3. Mechanical manufacturing field
Mechanical equipment: SS400 steel sheet is also widely used in the field of mechanical manufacturing. It is often used to manufacture bases, brackets, bearing seats and other parts of various mechanical equipment. These parts need to have good mechanical properties and wear resistance to ensure the stable operation and long-term use of mechanical equipment.
Heavy machinery: In addition, SS400 steel sheet is also suitable for manufacturing parts of heavy machinery and equipment. These equipment usually need to work in harsh environments and have high requirements for material performance.

4. Shipbuilding field
Hull structure: In the field of shipbuilding, SS400 steel sheet is used to manufacture hull plates, decks, bulkheads and other parts. These parts need to withstand the corrosion of seawater and the impact of waves, and SS400 steel sheet ensures the structural strength and navigation safety of the ship due to its good corrosion resistance and impact resistance.
In marine engineering, SS400 steel sheet is also used to manufacture structures such as offshore platforms.

5. Vehicle manufacturing field
Vehicle structure: SS400 steel sheet also has important applications in the field of vehicle manufacturing. It is often used to manufacture frames, axles, wheels and other parts. These parts have high requirements for the strength and toughness of the material to ensure the safety and stability of the vehicle.

6. Pressure vessels and storage tanks
SS400 steel sheets are also used to manufacture various pressure vessels and storage tanks due to their good mechanical properties and corrosion resistance. These equipment need to withstand extreme conditions such as high pressure and high temperature, and SS400 steel sheets can ensure the safety and stability of the containers.

7. Pipelines and transportation equipment
In the petroleum, chemical and other industries, SS400 steel sheets are used to manufacture various industrial equipment such as pipelines and conveyor belt brackets.

8. Other fields
SS400 steel sheets can also be used to make large motors, housings and bases of various pumps, etc. These applications make full use of the good mechanical properties and processing properties of A36 steel sheets.

In summary, SS400 steel sheets play an important role in many fields such as construction and machinery manufacturing due to their excellent performance and wide range of applications.
